6-36887-18-L-1_kd30

6-36887-18-L-1

Part No.6-36887-18-L-1
EAN
Further product information Variants
Area of application
Window technology
Area of application (specified)
Tilt&Turn, Turn-Only, Tilt-First
Application system
UNI-JET M6/4, UNI-JET M6/12
Product type
Rebate corner-hinge
Packing unit
1
Minimum ordering unit
1
Login

Please enter your login credentials to view prices or to order items

Content

UNI-JET HIGHER POSITIONED CORNER REBATE-HINGE M6 12/18-13, WITH BRAKE, WITHOUT H

Attributes

Furnishing
Vertical with, Horizontal without
Clearance
4 mm
Clearance 2
12
Height adjustment
Lower 2 mm, Lift 2 mm
Max. sash weight
130 kg
Axis
13 mm
Opening direction of hinges
Left
Profile material
timber
System
4/18-13, 12/18-13
Overlap width
18 mm

Catalogue data in PDF format

6-36887-18-L-x_kd01.pdf
PDF (1MB)
Deutsch, Englisch
Variants
The following variants are available for this product:
article
article description
6-36887-18-R-1_kd30
6-36887-18-R-1 | Rebate corner-hinge | REBATE CORN. HINGE UNI-JET M6 13mm W.BR
Rebate corner-hinge, overall width 153,7 mm, overall height / depth 38 mm, overall length 117,5 mm, Furnishing Vertical with, Horizontal without, Opening direction of hinges Right
