B-00550-03-0-8
Part No.B-00550-03-0-8
EAN
4 Variants found
No content available
Attributes
Backset
55 mm
Faceplate length
235 mm
Faceplate width
20 mm
Type of faceplate
Flachstulp
Finish of faceplate
matt
Version
With deadbolt
Single-component material lock case
Steel
Single-component material deadbolt
Zinc die-cast
Single-component material roller latch
Brass
Single-component material faceplate
Stainless steel
Colour of faceplate
stainless steel
Number of leaves
einflügelig
Finish of latch
nickel-plated
Finish of lock case
galvanised
Deadbolt throw
20 mm
Max. adjustable range of roller latch
12 mm
Min. adjustable range of roller latch
4 mm
Characteristic of roller latch
with silent latch feature, adjustable
Lock case
closed
Width of lock case
84,5 mm
Length of lock case
165 mm
Thickness of lock case
15,5 mm
Deadbolt
2-turn
Characteristic of faceplate
projecting on both sides
Faceplate thickness
3 mm
Type of door
Entrance door
Door characteristic
Rebated door
Door material
Holz
Opening direction of hinges
Left/right
