B 2390 0295
Part No.B 2390 0295
EAN
18 Variants found
B 2390 0241 | Mortise lock | 65/lipped facepl.24/36,round,DIN right
Part No.B 2390 0241
EAN
B 2390 0242 | Mortise lock | 65/lipped facepl.24/36,round,DIN left
Part No.B 2390 0242
EAN
B 2390 0267 | Panic shoot-bolt lock | 80/lipped facep.24/36,round,DIN right
Part No.B 2390 0267
EAN
B 2390 0268 | Panic shoot-bolt lock | 80/lipped facep.24/36,round,DIN left
Part No.B 2390 0268
EAN
B 2390 0293 | Mortise lock | 65/angular facep.22x12x3,round,DIN right
Part No.B 2390 0293
EAN
B 2390 0294 | Mortise lock | 65/angular facep.22x12x3,round,DIN left
Part No.B 2390 0294
EAN
B 2390 0296 | Mortise lock | 80/angular facep.20x12x3,round,DIN left
Part No.B 2390 0296
EAN
B 2390 0647 | Mortise lock | 65/adapter face.24x350,square,DIN right
Part No.B 2390 0647
EAN
View all variants
No content available
Attributes
Backset
80 mm
Panic function
Yes
Faceplate length
235 mm
Interior square of follower
9 mm
Type of faceplate
Angled faceplate
Finish of faceplate
matt
Cutout
with latch and deadbolt cutout
Version
for automatic locking
Follower
One-piece
Single-component material lock case
Steel
Single-component material follower
Steel
Single-component material faceplate
Stainless steel
Colour of faceplate
stainless steel
Number of leaves
2-leaf
Finish of lock case
galvanised
Deadbolt projection
3,5 mm
Lock case
closed
Width of lock case
110 mm
Length of lock case
165 mm
Thickness of lock case
16 mm
Characteristic of faceplate
projecting on both sides
Faceplate thickness
3 mm
Type of door
Smoke protection door, Anti-panic door, Fire protection door, Escape door
Door characteristic
Rebated door
Door material
Holz, Steel
Opening direction of hinges
Right
Interior square of follower
9 mm
Version
for automatic locking
Faceplate length
235 mm
Cutout
with latch and deadbolt cutout
Single-component material lock case
Steel
Single-component material faceplate
Stainless steel
Follower
One-piece
Single-component material follower
Steel
Number of leaves
2-leaf
Finish of lock case
galvanised
Lock case
closed
Width of lock case
110 mm
Length of lock case
165 mm
Thickness of lock case
16 mm
Characteristic of faceplate
projecting on both sides
Faceplate thickness
3 mm
Type of door
Smoke protection door, Anti-panic door, Fire protection door
Opening direction of hinges
Right
